Specification overview
Rated input power
1,100 W
Impact energy
8,5 J
Impact rate at rated speed
1500 - 2900 bpm
Rated speed
170 - 340 rpm
Weight
6.8 kg
Tool holder
SDS-max
Drilling range
Drilling dia. concrete, hammer drill bits
12 - 40 mm
Opt. appl. range concrete, hammer drill bits
18 - 32 mm
Drilling dia. concrete, breakthrough drill bits
45 - 55 mm
Drilling diameter in concrete with core cutters
40 - 90 mm
Max. drilling diameter masonry, core cutters
90 mm
Max. drilling diameter concrete
40 mm
Hammer drilling in concrete
Vibration emission value ah
14 m/s²
Uncertainty K
1.5 m/s²
Chiselling
Vibration emission value ah
11.5 m/s²
Uncertainty K
1.5 m/s²
Construction
The professional power tools for construction from Bosch.
