Technical data
Specification overview
Torque (soft/hard/max.)
24/63/- Nm
No-load speed (1st gear / 2nd gear)
0 – 500 / 0 – 1900 rpm
Chuck capacity, min./max.
1,5 - 13 mm
Battery voltage
18 V
Weight excl. battery
1.2 kg
Torque settings
20+1
Drilling diameter
Max. drilling diameter in wood
38 mm
Max. drilling diameter in steel
13 mm
Max. drilling diameter in masonry
13 mm
Screw diameter
Max. screw diameter
8 mm
Drilling in metal
Vibration emission value ah
2.5 m/s²
Uncertainty K
1.5 m/s²
Impact drilling in masonry
Vibration emission value ah
13.5 m/s²
Uncertainty K
1.5 m/s²
Screwdriving
Vibration emission value ah
2.5 m/s²
Uncertainty K
1.5 m/s2
